Thermal Module
Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays
Resolution 640 × 512
Pixel Pitch 17 μm
Spectral Range 8 μm to 14 μm
NETD ≤ 35 mK (@25°C, F# = 1.0)
Focal Length 50 mm
Focus Mode Semi-auto & Manual
IFOV 0.68 mrad
Aperture F1.0
Field of View 12.4° × 10° (H × V)
Min. Focusing Distance 5 m
Digital Zoom ×2, ×4, ×8
Optical Module
Image Sensor 1/1.8'' Progressive Scan CMOS
Resolution 2688 × 1520, 4 MP
Min. Illumination Color: 0.005 Lux @ (F1.3, AGC ON), B/W: 0.001 Lux @ (F1.3, AGC ON)
Field of View 56.6° × 33.7° (H × V) to 1.8° × 1.0° (H × V)
Focal Length 6 to 240 mm, 40x
Aperture (Range) F1.3 to F4.6
Focus Mode Semi-auto, manual
Digital Zoom ×2, ×4, ×8, ×16
Shutter Speed 1 s to 1/100,000 s
Day & Night Mode IR Cut Filter
WDR 120 dB
Optical Defog Yes
Image Effect
Picture in Picture Display partial image of thermal channel on the full screen of optical channel
Target Coloration Yes. Supported in white hot and black hot mode.
PTZ
Movement Range Pan: 360° Continuous Rotate; Tilt: From -90° to +90° (auto flip)
Pan Speed Configurable, From 0.01°/s to 40°/s
Tilt Speed Configurable, From 0.01°/s to 40°/s
Proportional Zoom Yes
Presets 300
Patrol Scan 8; Up to 32 presets per patrol
Pattern Scan 4; More Than 10 Minutes Per Pattern
Power Off Memory Yes
Park Preset/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PT Status Turn On/Turn Off
Scheduled Task
Preset/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama
Scan/Dome Reboot/Dome Adjust/Aux Output
Illuminator
IR Distance Up to 200 m
IR Intensity and Angle Automatically adjusted
Smart Function
VCA
4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), 10
scenes and 8 VCA rules for each scene.
Temperature Measurement
3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene
(10 points, 10 areas, and 1 line)
Temperature Range -20°C to 550°C (-4°F to 1022°F)
Temperature Accuracy Max (± 2°C, ± 2%)
Fire Detection
Dynamic fire and smoke detection, up to 10 fire points and 10 smoke points
detectable.
Video and Audio
Main Stream
Optical channel
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720)
Thermal channel
50 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 512, 384 × 288)
Sub-stream
Optical channel
50 Hz: 25fps (704 × 576, 352 × 288)
60 Hz: 30 fps (704 × 576, 352 × 288)
Thermal channel
50 fps (704 × 576, 640 × 512, 384 × 288)
Video Compression
Main stream: H.265+/H.265/H.264+/ H.264
Sub-stream: H.265/H.264/MJPEG
Audio Compression G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC/PCM
Network
Protocols
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP,
RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, SSH
Network Storage
MicroSD/SDHC/SDXC card (256 GB local storage, and NAS (NFS, SMB/CIFS), auto
network replenishment (ANR)
API
ISAPI, HIKVISION SDK, third-party management platform, Open Network Video
Interface (Profile S, Profile G)
Simultaneous Live View Up to 20 channels
User/Host level Up to 32 users. 3 levels: administrator, operator, user
Security
User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE
802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Client iVMS-4200, Hik-Connect
Web Browser
Live view (plug-in allowed) : Internet Explorer 11
Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +
Local service : Chrome 57.0 +, Firefox 52.0 +
Interface
Alarm Input 7-ch inputs (0 to 5 VDC)
Alarm Output 2-ch relay outputs, alarm response actions configurable
Alarm Action
Preset/patrol scan/SD card record/relay output/smart capture/FTP upload/email
linkage
Audio Input LINE_IN Input/MIC Input; Peak: From 2 to 2.4 V[p-p]; Output Impedance: 1 KΩ ± 10%
Audio Output Linear Level; Impedance: 600 Ω
