1/2.8" Progressive Scan CMOS; H.265+/H.265/H.264+/H.264/MJPE

Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Max. Resolution
1920 × 1080
Min. Illumination
0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light
Shutter Time
1/3 s to 1/100,000 s
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Lens
Lens Type
Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 107°, vertical FOV 56°, diagonal FOV 127°

4 mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 99°

6 mm, horizontal FOV 55°, vertical FOV 30°, diagonal FOV 63°

Lens Mount
M12
Iris Type
Fixed
Aperture
F1.0
Depth of Field
2.8 mm, 1.7 m to ∞

4 mm, 2.3 m to ∞

6 mm, 5.3 m to ∞

DORI
DORI
2.8 mm, D: 46 m, O: 18 m, R: 9 m, I: 4 m

4 mm, D: 56 m, O: 22 m, R: 11 m, I: 5 m

6 mm, D: 83 m, O: 33 m, R: 16 m, I: 8 m

Illuminator
Supplement Light Type
White light
Supplement Light Range
40 m
Smart Supplement Light
Yes
Video
Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720)

60 Hz: 30 fps (1920 × 1080, 1280 × 720)

Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)

60 Hz: 30 fps (640 × 480, 640 × 360)
