1/3" Progressive CMOS, ICR, 2560x1440:15fps(P)/(N),

Camera
Image Sensor
1/3" Progressive Scan CMOS
Max. Resolution
2560 × 1440
Min. Illumination
B/W: 0.01 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100,000 s
Day & Night
IR cut filter
Angle Adjustment
Solar panel: tilt: -45° to 45°, rotate:-30° to 30°
Lens
Lens Type
Fixed focal lens, 4 and 6 mm optional
Iris Type
Fixed
Aperture
4mm: F1.28, 6mm: F1.6
Depth of Field
4 mm: 2.7 m to ∞

6 mm: 5.9 m to ∞

Focal Length & FOV
4 mm, Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93°

6 mm, Horizontal FOV: 49°, Vertical FOV: 26°, Diagonal FOV: 57°

Lens Mount
M12
DORI
DORI
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m

6 mm, D: 128 m, O: 50 m, R: 25 m, I: 12 m

Illuminator
Supplement Light Type
IR
Supplement Light Range
Performance mode: up to 30 m, proactive mode: up to 10 m
IR Wavelength
850 nm
Smart Supplement Light
Yes
Video
Main Stream
50 Hz: 12.5 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

60 Hz: 15 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

Sub-Stream
50 Hz: 12.5 fps (1280 × 720, 640 × 480, 640 × 360)

60 Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360)
