Operating System Linux
Storage Up to 3,000 valid cards; up to 100,000 records
Fingerprint Capacity Up to 3,000 fingerprints
Fingerprint Recognition Duration 1: N recognition duration (up to 3,000 fingerprints) <1s
FAR (False Accept Rate) ≤0.001%
FRR (False Rejection Rate) ≤0.01%
Fingerprint Recognizer Optical fingerprint recognizer module
External Card Reader Standard Wiegand 26/34
Card Reading Mode M1 card
Card Reading Distance ≤5 cm
Keyboard Keyboard (backlit)
Reset Key × 1
Communication Interface Wi-Fi, TCP/IP, RS-485 (for secure door control unit), Wiegand output (w26/w34) and input (Wiegand 26/34)
Transmission Rate TCP/IP: 10/100 Mbps, self-adaptive; RS-485: 19200 bps-N-8-1
Input Interface Door switch button x 1, door magnetic sensor x 1, tamper-resistant switch x 1, and alarm input x1
Output Interface Relay (lock output) x 1, doorbell output x 1, and alarm output x 1
USB USB 2.0
LCD Screen 2.4-inch (320 × 240 LCD-TFT display screen)
Audio 1 buzzer and 1 loudspeaker
LED Indicator Power/status (red/green), key backlight (white)
Certifications CE, FCC, UL 60950-1
Power Supply 12 VDC
Working Current 1 A (maximum)
Working Temperature 14° to 131° F (-10° to 55° C)
Working Humidity 10% to 90% (non-condensing)
