Dimensions Ø155 x 137 mm (Ø6.1 x 5.4")
Weight 1 kg (2.2 lb)
Enclosure material UV-resistant polycarbonate, stainless steel
Mount material Metal
Wind loading 50 N at 200 km/h (11.24 lbf at 125 mph)
Hardware
Processor Quad-Core ARM® Cortex® A7
Memory 256 MB DDR3
Networking interface (1) GbE RJ45 port
RF connections Internal
Max. power consumption 11W
Power method Passive PoE 2-pairs (4, 5+; 7, 8-)
Power supply 24V DC, 0.5A gigabit PoE adapter (Included)
Supported voltage range 22—27V DC
ESD/EMP protection Air/contact: ± 24kV
Ambient operating temperature -40 to 60° C (-40 to 140° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications FCC, IC, CE
NDAA Compliant Yes
Software
Operating modes PtP master or station
Ubiquiti specific features Integrated 60 GHz radio, discovery protocol
Security WPA2 AES only
Services UISP, ping watchdog, web server, SSH server, NTP client, system log, device discovery
Tools Antenna alignment, discovery utility, traceroute, speed test
Management interface UISP application (web/mobile)
Minimum software requirements Any modern web browser/iOS™ or Android™ based smartphone
RF
Operating frequency* 57,000 - 66,000 MHz
* Dependent on regional regulations.
Channel bandwidth 2160 MHz
Operating channels 58320, 60480, 62640, 64800 MHz
Beamwidth* Azimuth: 2° (-3 dB) / 3° (-6 dB)
Elevation: 2° (-3 dB) / 3° (-6 dB)
*The antenna is only vertically polarized.
Bluetooth 2400 - 2483.5 MHz
